Fujifilm XF 8-16mm f/2.8 R LM WR Lens

Fujifilm XF 8-16mm f/2.8 R LM WR Lens

• X-Mount Lens/APS-C Format
• 12-24mm (35mm Equivalent)
• Aperture Range: f/2.8 to f/22
• Four Aspherical Elements
• Three Super ED and Three ED Elements
• Nano-GI Coating
• Linear Autofocus Motor
• Weather-Sealed Construction
• Rounded 9-Blade Diaphragm

This new XF lens is designed for use with the X Series range of digital cameras. The XF 8-16mm f/2.8 R LM WR is a fast ultra-wide angle zoom lens that has a constant maximum aperture of F2.8 and is equivalent to 12-24mm in the 35mm format. It complements the other constant F2.8 zoom lenses (XF 16-55mm f/2.8 R LM WR and XF 50-140mm f/2.8 R LM OIS WR) to create a premium trio of lenses that covers the focal lengths equivalent from 12mm all the way to 213mm in the 35mm format. The lens'' outstanding edge-to-edge image-resolving performance and F2.8 maximum aperture makes this product a perfect choice for landscape and architecture photography with an emphasized sense of perspective, interior photography at restaurants and hotels, as well as nightscape and astrophotography.

The FUJINON XF 8-16mm f/2.8 R LM WR lens is able to utilize the full capability of FUJIFILM''s X-TransTM CMOS Sensor to achieve superb sharpness even when the aperture is wide open. It faithfully captures the atmosphere of each scene, thanks to the outstanding image-resolving performance and fast f-stop. The lens barrel is lightweight yet robust while also being resistant to dust, moisture and low temperatures down to -10 degrees Celsius, making it extremely reliable for professional photographers.

1. Main Features
(1) Ultra-wide angle zoom with a constant maximum aperture of f2.8
In order to provide an ultra-wide angle zoom of 8-16mm
(equivalent to 12-24mm in 35mm format) at a constant
maximum aperture of f2.8, this lens uses an impressive
20 elements in 13 groups. This includes four aspherical lens
elements to control distortion and spherical aberration, and
six ED lens elements including three super ED elements
to control lateral chromatic aberration. This design results
in advanced image-resolving performance across the zoom
range while maintaining a constant maximum aperture of f2.8.

(2) Field curvature correction mechanism
In order to correct field curvature, typically found with ultra-wide angle lenses, this lens features a correction element which adjusts according to the position of the zoom in order to achieve edge-to-edge sharpness.

(3) Double Nano-GI coating
The rear surface of the two front lens elements is treated with Nano-GI coating to eliminate ghosting and flare, caused by oblique light, creating clear images.

(4) Silent and fast autofocus
The lens uses linear motors for autofocus to achieve quiet and ultra-fast AF.

(5) Advanced construction that withstands various shooting conditions
The barrel is sealed at 11 places to make the lens resistant to dust,
moisture, and low temperatures down to -10 degrees Celsius.
The front lens element is coated with fluorine to repel water and dirt,
adding extra durability so that the lens can be used outdoors with peace of mind.

(6) Accessories
Ultra-wide angle lenses have large front element protrusion and cannot be fitted with a regular lens cap. The FLCP-8-16 front lens cap is specifically designed for this lens and will be released on the market at the same time as the lens.

2. Main Specification
XF 8-16mm f/2.8 R LM WR
Type FUJINON LENS XF 8-16mm f/2.8 R LM WR
Lens configuration 20 elements 13 groups
(includes 4 Aspherical elements, 3 ED elements,
3 super ED elements)
Focal length (35mm format equivalent) f=8-16mm (12-24mm)
Angle of view 121°- 83.2°
Max. aperture F2.8
Min. aperture F22
Aperture control
Number of blades
Stop size
9(rounded diaphragm opening)
1/3EV (19 steps)
Focus range 25cm~8
Max. magnification 0.1x (Telephoto)
External dimensions: Diameter x Length (approx.)
(distance from camera lens mount flange) F88mm x 121.5mm

Weight (approx.) - excluding caps 805g
Accessories included Lens cap FLCP-8-16
Lens rear cap RLCP-001
Wrapping Cloth
